JEKYLL 29 SPARES - IDLER PULLEY 2021-2024
SPECIFICATIONS
Rear Travel - 165mm
Head Tube - UPR: 1-1/2” LWR: 1.8”
Headset - 1.125 - 1.5 tapered, IS42 top, IS52 lower
Bottom Bracket: Type / Width - BSA Threaded/73mm
Front Derailleur - N/A
Seat Post: Dia./Binder - 31.6mm / 34.9mm
Min. Seat Post Insert - 100 mm
Max. Frame Seat Post Insert Depth - SM: 250mm MD-LG: 275mm XL 286mm
Tire Size x Max. Width - 29” x 2.5” (measured)
Max. Fork Length - 581mm
Fork Travel / Offset - 170mm / 581mm
Rear Shock: Eye-to-Eye / Stroke / Bushing Width - 205 mm / 65 mm /FT: M8 x 30mm, RR: Trunnion Frame Mount
Sag - 25%-30%, 15 mm - 20 mm
Chain Guide - BB Shell: ISCG05
Idler - K22031 Jekyll Idler Guide
Rear Brake Mount / Type - Post Mount
Min / Max Rotor Diameter - 180mm / 203mm
Axles: Type/Length - 148x12 Maxle TA M12 x 1.5p x 180mm Overall Length
Ai Offset - Rear Wheel: 3 mm Boost Ai Offset to NDS
Max. Weight Limit: Total - 138kg
|
