TOPSTONE CARBON SPARES 2020 - 2022
SPECIFICATIONS
Head Tube - Upper 1-1/8 in, LWR 1-1/2 in
Headset - IS42 Top IS52 Bottom 45/36
Bottom Bracket: Type / Width - BB30A / 83 mm
Front Derailleur - Brazed-on
Seat Post: Dia./Binder - 27.2 mm / Internal Wedge
Minimum Seat Post Insert - 65 mm
Maximum Seat Post Insert - XS: 140 mm, S-XL: 188 mm
Tyre Size x Maximum Width - 700c x 40 mm (measured), 650b x 48 mm (measured)
Brakes: Mount Type / Min / Max Rotor Diameter - RR: Flat Mount / 140/160 mm FT: Flat Mount +20mm / 160 / 180 mm
Axles: Type / Length - RR: Speed Release, Double Lead / 142x12mmx1.0P, 165 mm Length FT: Speed Release, Double Lead / 100x12mmx1.0P, 119 mm Length
Ai Offset - Rear Wheel: 6mm Offset to NDS Hollowgram SpideRing: Standard with Ai Spindle
Maximum Weight Limit: Total - 138kg
|
