Jekyll 29 Spares 2019 - 2020

Jekyll 29 Spares - 2019 - 2020

• Rear Travel - 120mm / 150mm
• Head Tube - UPR: 1-1/2” LWR: 1.8”
• Headset - FSA Orbit C-40-ACB w/ 9.1 mm stack
• Bottom Bracket: Type / Width - PF30 / 83 mm
• Front Derailleur - N/A
• Seat Post: Dia./Binder - 31.6mm / 34.9mm
• Min. Seat Post Insert - 100 mm
• Tire Size x Max. Width - 29” x 2.5” (measured)
• Max. Fork Length - 565mm
• Rear Shock: Eye-to-Eye / Stroke / Bushing Width - 230 mm / 60 mm / FT: 30 x 8 mm, RR: 30 x 8 mm
• Sag - 30%, 18 mm
• Chain Guide - ISCG05
• Rear Brake Mount / Type - Flat Mount
• Min / Max Rotor Diameter - 160mm / 180mm
• Axles: Type/Length - Maxle TA / 148 x 12 mm, 180 mm length
• Ai Offset - Rear Wheel: 3 mm Offset to NDS, SRAM Chainring: +6 mm Offset, Hollowgram SpideRing: Ai Offset
• Max. Weight Limit: Total - 138kg
